InteliLite Global Guide
700
Firmware upgrade
Download the newest FWof module from ComAp website (in form of PSI file or installation package)
Instal package to computer or open PSI to instal it into InteliConfig
Plug the module into the controller and power the controller on.
Open a connection with controller via InteliConfig
Go the menu Tools -> Firmware upgrade, select the Plug-in modules tab and select the appropriate firmware
you want to program into the module (in InteliConfig).
Press the OK button to start upgrade of firmware.
The firmware update process may be performed via any kind of connection including connection via the same
module in which the firmware is to be updated. The connection is reestablished again automatically when the
update process is finished.
CM-4G-GPS
CM-4G-GPS plug-in module containing a GPS receiver and GSM/WCDMA/LTE modem which can works in
two modes of operation based on the settings in the setpoint Internet Connection (page 359).
Image 9.23 CM-4G-GPS module
IMPORTANT: Any manipulation with plug-in module shall be done with disconnected power
supply to controller.
IMPORTANT: CM-4G-GPS and CM-GPRS modules cant be used in one controller in the same time.
IMPORTANT: Operating temperature of module is from -30°C to +75°C.
Note: Cellular data service must be enabled in your SIM card by your mobile operator for successful operation.
CM-4G-GPS module works with:
WebSupervisor – internet-based remote monitoring solution
AirGate – powerful connection technology to make internet access as simple as possible
CM-4G-GPS module also works like GPS locator. Geo-fencing function can be used with this module.
Supported 4G bands are as follows:
FDD LTE: Band 1, Band 2, Band 3, Band 4, Band 5, Band 7, Band 8, Band 20, all bands with diversity
WCDMA/HSDPA/HSUPA/HSPA+: Band 1, Band 2, Band 5, Band 8, all bands with diversity
GSM/GPRS/EDGE: 850 MHz/900 MHz/1800 MHz/1900 MHz
