IS-NT-Async-SPI, SW Version 1.2, ©ComAp – February 2011
IS-NT-Async-SPI-1.2.PDF
29
PulseCounter 1
PulseCounter 2
PulseCounter 3
PulseCounter 4
The inputs are linked with corresponding counters, which integrate the pulses sensed at these inputs. Each
rising edge of the signal at input increases the internal counter value.
Hint:
Pulse width (both high/low levels) must be at least 100 ms in order to be correctly sensed!
Conversion ratio can be selected using the setpoints ConvCoefPulseX. The converted values are visible in
statistics – values PulseCounter X. These values can be reset using Statistics window in InteliMonitor.
Timer block 1
Timer block 2
Timer block 3
Timer block 4
Timer block 5
Timer block 6
Timer block 7
Timer block 8
Timer block 9
Timer block 10
Timer block 11
Timer block 12
Timer block 13
Timer block 14
Timer block 15
Timer block 16
Blocking inputs for particular timer module channels. The input can lock out its assigned channel – if this
input is active, the channel won’t activate its output (Timer active X) to e.g. start the engine.
Lang sel int A
Lang sel int B
Lang sel int C
Set of binary inputs for forcing alternative languages. This set of inputs is switching the controller’s internal
terminal – for IG-based controllers the front panel, for IS-based controllers the IS-Display with address #1.
