f To send the call from an external unit, touch the button corresponding to the user you want to contact.
If the system is not busy: on the external unit the caller illumination LED will light up, the
LED will flash and the
confirmation tone will sound. The video image from the external unit will appear automatically on the main internal
monitor/s. The video image can be displayed on secondary monitors (without answering the call) by pressing button 2
(programmed by default for the self-ignition function).
» If the user responds to the call: the LED
will illuminate on the external unit.
» If the user presses the lock-release control: the LED
will illuminate on the external unit.
If the system is busy: the led
will flash and the external unit will emit the system busy tone.
When a call is made from the external unit, the monitor switched on will be the main door entry monitor.
Any other secondary monitors in the same family unit will remain o.
When responding to a call from the external unit using a secondary door entry monitor, the image is automatically displayed on
the monitor (and the main door entry monitor is switched o).
To display the image without activating audio communication with the external unit, press button 2 -self-ignition/video request.
√ Self-ignition is possible only when the system is in standby
f Press the self-ignition button (button 2 by default) to display on the monitor the image transmitted from the external unit.
GENERAL INTERNAL CALL
SELECTIVE INTERCOM
MAIN/SECONDARY MONITORS
General intercom: function allowing calls to one or more internal units identified by the same call address as used by the
external unit.
f Press the programmed button to send the call
If the system is not busy: the receiver of the call can lift the handset (or press the audio button) to enter into
communication with the caller. The communication is terminated by replacing the handset (or by pressing the audio button
again).
If the system is busy: the LED indicator light will flash for a few seconds (on Mini monitors the privacy LED will flash 4
times).
A call from the external unit always takes priority over an intercom communication. In this case, users who are already
speaking will hear a tone similar to the ringtone, if the call is addressed to them, or otherwise a triple signalling tone will sound
and the video image from the external unit from which the call was made will appear (in the case of a main monitor).
f To terminate the call in progress and enter into communication with the external unit, hang up and then lift the handset
again (or press the audio button 2 times).
Consult page 11 onwards for programming information.
• External unit (Porter) with switching (secondary): default function to be used also in systems with switching device Art.
1404 (for installations with 3 or more entrances) (see diagrams MNK/017QC, MNK/017CQC).
• Secondary external unit (Porter): function to be used in systems with switching device Art. 1405 and 2 external units (see
diagram MNK/017AQC).
• Main external unit (Porter): function to be used in systems with switching device Art. 1405 and 2 external units (see
diagram MNK/017AQC).
Selective intercom: function allowing calls to one or more internal units identified by a dedicated call address (see table B,
page 19), which is dierent to the call address used for external unit calls.
The KIT can manage up to a maximum of 4 door entry monitors or door-entry phones for each call button, including a
maximum of 1 main door entry monitor.
Operation
To make a call from an external unit
Self-ignition
Operation with additional internal units
Operation with additional external units
