Comelit 8461M - KIT 8461 M-MB: Expansion with Second External Unit 4893 and Switching Device Art. 1405

32
KIT 8461M-MB: expansion with second external unit 4893 and switching device Art. 1405
MNK/017AQC
# To program the special functions “Main external unit (Porter)” and “Secondary external unit (Porter)”, see page 11.
For further information regarding operating modes, please refer to Operation section, page 26.
*
Local lock release button.
**
N.C. contact for door open indication.
***
Door open indication not available.
