RM5 XCC RM5 HDC
192 Req. build code RM5 HD XY RM5 HD XY
Note :
X= Edition
Y= Revision
By means of control 232 (Perform self-check), the ccTalk and FULL versions of the
RMD HD returns the events buffer, the result is reported on two byte as described in
the following table:
Data byte 0 Data byte 1 Meaning
0x00 0x00 self-check OK
0x01 0x00 EEPROM checksum error
0x02 0xXX
Inductive coils error. Data byte 1 is a bitmask
reporting which coil failed
0x03 0xXX
Coin output sensors error. Data byte 1 is a bitmask
reporting which coin output sensor failed (cash/reject)
0x06 0xXX
Diameter sensors error. Data byte 1 is a bitmask
reporting which diameter sensor failed
By means of control 229 (Read buffered credit or error codes), the ccTalk version of
the RMD HD returns the events buffer, where the following error codes can be found
in both ccTalk giochi Italia and ccTalk full versions:
ERROR DESCRIPTION NUMBER
REJECT COIN 1
CREDIT SEQUENCE
ERROR
16
INHIBITED COIN 2 COIN GOING BACKWARD 17
MULTIPLE WINDOW 3 COIN ON STRING 20
VALIDATION TIMEOUT 5
CREDIT SENSOR
REACHED TOO EARLY
23
CREDIT SENSOR TIMEOUT 6 REJECT COIN REPEATED 24
SORTER OPTO TIMEOUT 7 REJECT SLUG 25
2ND CLOSE COIN ERROR 8
REJECT SENSOR
BLOCKED
26
SORTER NOT READY 11 INHIBITED COIN 128÷159
VALIDATION SENSOR NOT
READY
13 FLIGHT DECK OPEN 254
CREDIT SENSOR BLOCKED 14
UNSPECIFIED ERROR
CODE
255
SORTER OPTO BLOCKED 15
