14
• service centres booklet;
• nozzle hexagonal key;
• nozzle cleaning pin.
If there are problems, contact your dealer or an authorised assistance centre.
OPTIONAL ACCESSORIES
The following range of accessories can be added to the standard high-pressure cleaner equipment:
• rotating nozzle lance: designed for the removal of stubborn grime (standard on
EXTRA
);
• sandblasting lance: designed for sanding surfaces, removing rust, paint, incrustations, etc.;
• rotating water jet brush: designed for cleaning delicate surfaces;
• xed water jet brush: designed for cleaning delicate surfaces. (standard on
EXTRA
);
• Pipe ushing probe: designed for unblocking pipes and ducts;
• oor cleaning lance;
• high pressure hose extension kit 8 m/26 ft: ideal for increasing the cleaning surface;
INSTALLATION AND ACCESSORIES ASSEMBLING
In order to prevent damages to the high pressure cleaner, the following operations should be done
by two persons.
• Carefully extract the high pressure washer from the carton box, paying attention not to damage it or let it
fall down.
SEE PICT. 4a
.
• Insert till the end the foot (27) on the high pressure washer frame, checking the correct positioning.
SEE
PICT. 4b
.
• Lock the foot with the 2 screws supplied (cross screew driver not supplyed).
SEE PICT. 4c
.
• Mount the wheel (24), until you hear a “click”.
SEE PICT. 4d
.
• Insert till the end the Hose reel knob (21).
SEE PICT. 4e
.
• Mount and push till it’s completely locked the handlebar (3). Double check that the handlebar is completely
insered into the machine frame (frontal surfaces must be aligned). Lock the handlebar with the 2 screws
supplied (cross screw driver not supplied).
SEE PICT. 4f
.
• Screw the high-pressure pipe connector (23) to the thread of the gun (14) and fully tighten with a 17mm/0,67
in spanner (not supplied).
OPERATION A PICT. 9
OPERATION PRELIMINARY OPERATIONS
• Take the high pressure water cleaner to the work position, getting hold of its handle (2).
SEE PICT. 5
. Use
the lifting handle (10) and handlebar (3) for lifting
SEE PICT. 6.
• Completely unreel the high pressure hose (23).
• Insert the high pressure hose quick coupler (30) on the outlet coupling (29), and fully tighten the ring nut
by hand (only
CLASSIC
).
SEE PICT. 1.
• Seecure a supply hose to the quick-release water inlet tting (12) using a general-purpose gardening
quick-release tting.
OPERATION B PICT. 9
.
• Open the water supply tap, making sure there is no dripping.
OPERATION C PICT. 9
.
• Make sure the main ON/OFF switch (2) is turned to “0” and connect the plug
OPERATION D PICT. 9
.
• Turn the main ON/OFF switch (2) to position “1”.
• Press the lever (26) of the high pressure water cleaner and wait for water to ow out continuously
• Switch the main ON/OFF switch (2) to position “0” and connect the spray lance (15) or (18) to the water
gun(14), tightening rmly.
OPERATION E PICT. 9
.
STANDARD OPERATION AT HIGHPRESSURE
• Check that the nozzle head (16) is not in the detergent distribution position (see also paragraph
“OPERATION
WITH DETERGENT”
).
• Re-start the high pressure water cleaner again, switching the main ON/OFF switch (1) to position “2”.
NOTE:
when starting in this phase, the high pressure water cleaner will stop immediately after the starting
breakaway because the
TOTAL STOP
device trips.
