Comm-Tec UP-51TS - 6 Panel Drawing

Compact Scaler Switcher
Comm-Tec S.r.l. 41 www.comm-tec.it
General
Transmission Distance
1080P≤70m(Cat6)
Temperature
0 ~ +50℃
Humidity
10% ~ 90%
Power Supply
DC24V 2.71A
Power Consumption
27W
Dimension (W*H*D)
220mm x 44mm x 172.5mm
Weight
800g
6. Panel Drawing
SOU RCE
MIC
VOL UME
IR 1-HDMI/MHL 5-V GA4-D P3-HDMI2-H DMI AUTO
ENT ER MENU/ 2s
5-input Seamless Scaler Switcher with HDBaseT
DC 24 V 48V
LIN E IR EYEIR IN IR O UT
MIC INPU T
MIC
FIR MWARE
AUDI O OUT
L R
RES R ESET
RS2 32
Tx
Rx
INP UTS OUTPUTS
3-H DMI2-HD MI1 -HDMI / M HL 4 -DP 5-V GA HDM I
HDB T
CONTRO L
220 mm
172.5 mm
44 mm
