Community R.5 - R.5 COAX Specifications*

Community R-Series Installation/Operation Manual for Models R.5 and R.25 — Page 30
MODEL R.5COAX66 R.5COAX66T R.5COAX99 R.5COAX99T
Type Two-way, full-range, coaxial loudspeaker systems, weather-resistant
Frequency
Range
80 Hz - 18 kHz
(90 Hz - 12.5 kHz ±3.5 dB)
80 Hz - 18 kHz
(90 Hz - 13 kHz ±3.5 dB)
80 Hz - 18 kHz
(90 Hz - 12.5 kHz ±3.5 dB)
80 Hz - 18 kHz
(90 Hz - 13 kHz ±3.5 dB)
Maximum Input
200W RMS, 500W PGM
40V RMS, 89V peak
70V Taps: 200W, 100W,
50W, 25W
100V Taps: 200W, 100W,
50W
200W RMS, 500W PGM
40V RMS, 89V peak
70V Taps: 200W, 100W,
50W, 25W
100V Taps: 200W, 100W,
50W
Suggested
Amplifier Power
420W - 600W @ 8 ohms
200W, 70V/100V line
transformer
420W - 600W @ 8 ohms
200W, 70V/100V line
transformer
Sensitivity
(1W/1m)
98 dB SPL (100 Hz to 12.5
kHz 1/3 octave bands)
97 dB SPL (100 Hz to
12.5 kHz 1/3 octave
bands)
96 dB SPL (100 Hz to
12.5 kHz 1/3 octave
bands)
95 dB SPL (100 Hz to
12.5 kHz 1/3 octave
bands)
Maximum SPL
121 dB SPL at 1 meter 120 dB SPL at 1 meter 119 dB SPL at 1 meter 119 dB SPL at 1 meter
Nominal
Dispersion
60° H x 60° V 90° H x 90° V
Nominal
Impedance
8 ohm
(min 4.2 ohms @ 9.9 kHz)
Depends on tap selected
8 ohm
(min 3.8 ohms @ 9.9 kHz)
Depends on tap selected
Crossover
Frequency
2 kHz
Components
LF: 1 x 12” (305mm) cone driver
HF: 1 x 1" (25.4mm) exit, non-metallic, compression driver, Ferrofluid-cooled
Driver
Protection
DYNA-TECH™
Recommended
High Pass Filter
60 Hz, 24 dB/octave 80 Hz, 24 dB/octave 60 Hz, 24 dB/octave 80 Hz, 24 dB/octave
Input
Connection
Approx. 12 ft (4m) SJOW
16 Gauge cable
(white = +, black = –)
Approx. 12 ft (4m) SJOW
16 Gauge cable
(white = +, black = –)
Approx. 12 ft (4m) SJOW
16 Gauge cable
(white = +, black = –)
Approx. 12 ft (4m) SJOW
16 Gauge cable
(white = +, black = –)
Enclosure
Material
Roto-molded gray polyethylene
Grille
Three-layer stainless steel WeatherStop™ grille, light grey
(Zinc-rich epoxy dual-layer powder coated perforated steel grille, foam, woven poly mesh)
Mounting Five 3/8-16 rigging points
Accessories
(Included)
Light grey, powder coated steel yoke bracket, multi-angle aiming strap
Dimensions
(HWD)
16 x 16 x 15.94 inches (406.4 x 406.4 x 404.88 mm)
Weight 35 lbs (15.9) kg 38.5 lbs (17.4 kg) 35 lbs (15.9) kg 38.5 lbs (17.4 kg)
R.5COAX SPECIFICATIONS*
* Community strives to improve its products on a continual basis. Specifications may therefore be subject to change without notice.
R.5COAX Specifications
