MODEL R.5SUB R.5SUB-T
Type
Compact subwoofer, vented enclosure, weather-resistant
Frequency Range
45 Hz – 150 Hz (50 Hz – 100 Hz ±3.5 dB)
Maximum Input
200W RMS, 500W Program
35 volts RMS, 77 volts peak
70V: 200W, 100W, 50W, 25W taps
100V: 200W, 100W, 50W taps
Recommended
Amplifier Power
420W - 600W @ 6 ohms up to 200W @ 70V or 100V
Sensitivity (1W/1m)
91 dB (63 Hz to 160 Hz 1/3 octave bands) (90 dB for T version)
Maximum SPL
119 dB at 1 meter (118 dB for T version)
Nominal Dispersion
360° H x 180° V
Nominal Impedance
6 ohm (min 5.4 ohms @ 87 Hz) Depends on tap selected
Crossover Frequency
Internal passive 120 Hz, 12 dB/octave low pass filter
Components
LF: 1 x 12 in. (305mm) driver
Driver Protection
None
Recommended
High Pass Filter
45 Hz high pass filter, 24 dB/octave minimum
Input Connection
Approx. 12 ft (4m) SJOW 16 Gauge cable
(white = +, black = –)
Approx. 12 ft (4m) 5 conductor 18 Gauge
cable
Enclosure Material
Roto-molded gray polyethylene
Grille
Three-layer stainless steel WeatherStop™ grille, light grey
(Zinc-rich epoxy dual-layer powder coated perforated steel grille, foam, woven poly mesh)
Mounting
Five 3/8-16 rigging points
Accessories
(Included)
Light grey, powder coated steel yoke bracket, multi-angle aiming strap
Dimensions (HWD)
16 x 16 x 16 inches (406.4 x 406.4 x 406.4 mm)
Weight
35 lbs (15.9) kg 39 lbs (17.7 kg)
R.5SUB SPECIFICATIONS*
R.5SUB Specifications
* Community strives to improve its products on a continual basis. Specifications may therefore be subject to change without notice.
