Community R-Series Installation/Operation Manual for Models R.5 and R.25 — Page 34
MODEL R.5-66Z and R.5-66TZ R.5-94Z and R.5-94TZ R.5-99Z and R.5-99TZ
Type
Two-way, horn loaded, full-range loudspeaker system, weather-resistant
Frequency Range
85 Hz – 16 kHz (125 Hz – 10 kHz +/-4 dB)
Maximum Input
8 ohm Versions: 200W RMS, 500W Program, 40V RMS, 89V momentary peak
“TZ” Suffix: 200W, 100W, 50W, 25W taps for 70V line, 200W, 100W, 50W taps for 100V line
Recommended
Amplifier Power:
8 ohm Versions: 420W – 600W RMS @ 8 ohm
“TZ” Suffix: up to 200W RMS @ 70V or 100V
Sensitivity (1W/1m)
103 dB / 102 dB (TZ) 101 dB / 100 dB (TZ) 101 dB / 100 dB (TZ)
Maximum SPL
126 dB / 125 dB (TZ) 124 dB / 123 dB (TZ) 124 dB / 123dB (TZ)
Nominal Dispersion
60° H x 60° V 90° H x 40° V 90° H x 90° V
Nominal Impedance
R.5-66Z: 8 ohm (min 4.1 Ω @
9.6 kHz)
R.5-66TZ: Depends on tap
selected
R.5-94Z: 8 ohm (min 4.2 Ω
@ 9.7 kHz)
R.5-94TZ: Depends on tap
selected
R.5-99Z: 8 ohm (min 4.2 Ω
@ 9.5 kHz)
R.5-99TZ: Depends on tap
selected
Crossover
Frequency
2 kHz
Components
LF: 1 x12" (305mm) Ferrofluid-cooled driver
HF: 1 x 1" (25.4mm) exit, non-metallic, compression driver, Ferrofluid-cooled
Driver Protection
DYNA-TECH™
Recommended
High Pass Filter
90 Hz high pass filter, min 24 dB/octave
Input Connection
Approx. 12 ft / 4m 16-2 SJOW cable (white = +, black = –)
Enclosure Material
Rotomolded gray polyethylene
Grille
Three-layer stainless steel WeatherStop™ grille, light grey
(Zinc-rich epoxy dual-layer powder coated perforated steel grille, foam, woven poly mesh)
Mounting
Five 3/8-16 rigging points
Accessory
(Included)
Light grey, powder coated steel yoke bracket, multi-angle aiming strap
Dimensions (HWD)
16 x 16 x 16 inches (406.4 x 406.4 x 406.4 mm)
Weight
8-ohm Versions: 35 lbs / 15.9 kg
“TZ” Suffix: 37 lbs / 16.8 kg
R.5Z SPECIFICATIONS*
R.5Z Specifications
* Community strives to improve its products on a continual basis. Specifications may therefore be subject to change without notice.
