Community R.5 - R.5 HP;HPT Specifications*; R.5 HP Specifications

Community R-Series Installation/Operation Manual for Models R.5 and R.25 — Page 32
MODEL R.5HP R.5HPT
Type
Three-way, horn loaded, full-range loudspeaker, weather-resistant
Frequency Range
90 Hz – 16 kHz (125 Hz – 12.5 kHz ± 6 dB)
Maximum Input
200W RMS, 500W Program
35 volts RMS, 77 volts peak
70V Taps: 200W, 100W, 50W, 25W
100V Taps: 200W, 100W, 50W
Recommended
Amplifier Power:
420W - 600W @ 6 ohms up to 200W @ 70V, 100V or 140V
Sensitivity (1W/1m)
106 dB SPL 105 dB SPL
Maximum SPL
129 dB SPL at 1 meter 128 dB SPL at 1 meter
Nominal Dispersion
60° H x 40° V
Nominal Impedance
6 ohm (min 3.2 ohms @ 11,220 Hz) Depends on tap selected
Crossover Frequency
600 Hz / 4 kHz
Components
LF: 1 x 12" (305mm) driver
MF: 1 x M200 Community driver
HF: 1 x 1" (25.4mm) exit, non-metallic, compression driver, Ferrofluid-cooled
Driver Protection
None
Recommended
High Pass Filter
90 Hz, 24 dB/octave
Input Connection
Approx. 12 ft (4m) SJOW 16 Gauge cable
(white = +, black = –)
Approx. 12 ft (4m) 5 conductor
18 Gauge cable
Enclosure Material
Roto-molded gray polyethylene
Grille
Three-layer stainless steel WeatherStop™ grille, light grey
(Zinc-rich epoxy dual-layer powder coated perforated steel grille, foam, woven poly mesh)
Mounting
Five 3/8-16 rigging points
Accessories
(Included)
Light grey, powder coated steel yoke bracket, multi-angle aiming strap
Dimensions (HWD)
16 x 16 x 16.19 inches (406.4 x 406.4 x 411.2mm )
Weight
42.3 lbs (19.2 kg) 45.5 lbs (20.6 kg)
R.5HP/HPT SPECIFICATIONS*
R.5HP Specifications
* Community strives to improve its products on a continual basis. Specifications may therefore be subject to change without notice.
