Community R-Series Installation/Operation Manual for Models R.5 and R.25 — Page 33
Version Black White Brown Orange Yellow Red
R.5HP (6 ohm) Negative Positive N/A N/A N/A N/A
R.5HPT, 70V Negative N/A 200W 100W 50W 25W
R.5HPT, 100V Negative N/A N/A 200W 100W 50W
R.5HP/HPT SPECIFICATIONS*
R.5HP Input Connection Guide
R.5HP Dimensions
R.5HP Yoke Mounting Bracket (included)
