ENGLISH
Operator’s handbook
4. LIFTING
Since the machine is compact and does not weigh
much, it can be easily lifted and moved by picking up
the package (fi g. 7) using the punch out handles on
the sides of the package, or using a handtruck.
In the event of storing or moving the ma-
chine, pay close attention to the pictogram
on the package. It indicates the maximum
number of pieces which can be safety sta-
cked. In the event of shipping on a truck or
similar vehicle, make sure that the package
is securely anchored to prevent it from
overturning.
Avoid bumping or stress to protect the
perfect operation of the machine and the
safety of individuals around it.
5. INSTALLATION
5.1 Installation
All of our machines undergo a strict acceptance test
in our plant and are normally shipped in perfect
assembly conditions. If you discover damage to the
machine when you receive it, inform the shipper im-
mediately. Also make sure all the standard machine
equipment is included:
Spanner set for normal maintenance
Use and instruction manual
Declaration of conformity
Stop rod
Mod. JET
Piece pusher for upper surface work
Lower guard
Upper support square
Make sure that all the standard and optio-
nal accessories are included which appear
on the shipping document.
5.2 Lifting
Since the machine is compact and does not weigh
much, it can be easily lifted and moved by picking up
the package (fi g.8) using the punch out handles on
the sides of the package, or using a handtruck.
In the event of storing or moving the ma-
chine, pay close attention to the pictogram
on the package. It indicates the maximum
number of pieces which can be safety sta-
cked. In the event of shipping on a truck or
similar vehicle, make sure that the package
is securely anchored to prevent it from
overturning. Avoid bumping or stress to
protect the perfect operation of the machi-
ne and the safety of individuals around it.
5.3 Positioning
Place the machine on a work bench approximately 90
cm high, with a surface of at least 60 x 80 cm.
Make sure to choose an area with adequate lighting
and enough space around the machine for cutting
the pieces to be processed.
It is also important to leave a space around the ma-
chine of at least 80 cm.
Make sure it is well balanced and level. Anchor the
machine to a stable structure using the two holes
