18
FACTORY MENU
In the event that a CompAirTroller (CAT) has to be replaced additional programming to that done by
user and service personnel is required.
After the unit is powered up the “Factory Menu” is accessed by holding in both “UP”↑ and “DOWN”↓
arrow keys simultaneously for ten (10) seconds. When all LED’s flash, push “UP” ↑ arrow key until
“48” shows in display, then push “STOP” key until display stops flashing.
The Factory Menu can now be observed by pushing the Select Button.
DISPLAY LED FUNCTION
PSI/bar Line Pressure Pressure Units
FAHr/cELS Compressor Temperature Temperature Units
XXXX Compressor Temperature Alarm Temperature
*AlAr/Coutr Aux. Contact Configuration
tP-XX Compressor Configuration Model
(Ref. Table B)
Stopt/XXX Stop Delay after Stop pushed
(Normal Stop)
Total/XXXX Running/Loaded Hours Hour Meter
Load/XXXX Running/Loaded Hours Hour Meter
Scroll through the menu by pushing select and set the following function. Setting the functions is
done by pushing the “UP” ↑ and “DOWN”↓ arrow keys.
• Pressure Units
• Temperature Units
• Compressor Configuration Model Number (see table on next page)
• Total Hours
• Loaded Hours
The stop delay may be altered if other than the normal ten seconds is desired.
* The auxiliary contact configuration is used when a sequencer is used or remote annunciation is
required.
Coutr For sequencer use
AlAR For alarm circuit
Push reset after above parameters are entered to exit menu.
Set service timers by entering service menu.
Display will indicate “READY”. Unit is ready to start.
