23
MOUNTING AND
SPACE REQUIREMENTS
A suitable smooth floor should be provided for
placing the compressor.
A special foundation is not required unless
the floor or other mounting surface is
extremely rough or unable to support the
weight of the unit. The unit should sit level. It
is advisable to use shims, as required, to
make certain the tank feet (or Bed plate) are
resting firmly on the mounting surface.
If there is danger of the unit being moved out
of position for any reason, it may be loosely
bolted to the mounting surface.
Adequate space must be provided to service
the unit once it is installed. All units must be
positioned at least 24” away from a wall or
other obstruction on all sides to allow
adequate cooling air circulation and service
access.
Table II shows the approximate overall
dimensions and weights which may be used
for selecting a suitable location for the
compressor.
TABLE II
DIMENSIONS AND WEIGHTS
TANK MOUNT (120 GAL.)
MODEL LENGTH, IN. WIDTH, IN. HEIGHT, IN. WEIGHT, LBS.
CL15SS,CUB 69.0 33.43 62.43 1075
CL20SS,CUB 69.0 33.43 62.43 1125
CL25SS,CUB 69.0 33.43 62.43 1175
CL30SS,CUB 69.0 33.43 62.43 1200
BED PLATE MOUNT
CL15SS,CUB 50.0 33.42 34.0 700
CL20SS,CUB 50.0 33.42 34.0 750
CL25SS,CUB 50.0 33.42 34.0 800
CL30SS,CUB 50.0 33.42 34.0 825
ENCLOSED
CL15SS,CUB 54.5 49.0 40.0 860
CL20SS,CUB 54.5 40.0 40.0 1002
CL25SS,CUB 54.5 49.0 40.0 1144
CL30SS,CUB 54.5 49.0 40.0 1286
ELECTRICAL SUPPLY
An adequate electrical power supply of the
correct voltage must be provided. All control
enclosure wiring has been completed at the
factory. This includes magnetic starter wiring
for units furnished with starter. Units furnished
without a starter require wiring the starter on
the job site.
The electrical supply should be equipped with
a fused line disconnect switch or circuit
breaker so that electrical power may be
disconnected while the unit is being serviced.
The fuse line disconnect should be located
and mounted in accordance with all state,
local and national regulations.
The unit must be properly grounded to provide
adequate ground fault protection. As a guide,
it is suggested that the ground wire be equal
in size to one of the conductors which feeds
the compressor motor circuit. Make certain
SECTION IV
INSTALLATION
CL15-30 SS, CUB
