11. Annex
51
11.3 Layout plan L07-L11
FRONT VIEW
Compressed air connection
R3/4“
Electrical connection
Air inlet
Cooling-air outlet
Access panel
Service aperture (V-belt relief)
Oil drain R1/2“
Fig. 25
View “X”
REMOVABLE
HOOD
