K09652H00 | PROC-CAL/002/03 USER MANUAL | V. 29/06/20023
. ADJUSTMENT
. MAIN SWITCH
The main switch ( ) has the following
positions: OFF/ON.
K3 K6
Equipment ON ON ON
Equipment OFF OFF OFF
. UTILIZATION
Turn on the grinder using the ON – OFF switch
( ), the appliance starts grinding coee. The
grinder will stop grinding coee when the
dispenser reaches the maximum possible
capacity level in the dispenser and will restart
after serving approximately 8 doses of coee,
to return to its maximum level.
To serve the coee doses, place the filter holder
on the support fork ( ), bringing it to the
bottom so that it is under the ground coee
spout. Pull the dosing lever ( ) to obtain a
dose of coee (one dose corresponds to one
coee), and let the lever return to its position
without accompanying it (Fig. 1).
Fig. 1
. OPERATION
. REGULATION OF THE DOSE OF
COFFEE SERVED
The dispenser is factory calibrated to serve
about 7 grams of ground coee, but this
amount can be adjusted between 6 and 10
grams in the following way:
• Remove the dosing lid ( ) and turn
the adjustment bolt ( ); in a clockwise
direction we will obtain a smaller dose of
coee, and in an anti-clockwise direction
to obtain a larger dose (Fig. 3).
Fig. 3
• Once the dose has been adjusted, refit
the cover of the ground coee dispenser
with the dosing lid( ).
