viii Contents
7.13 Top Cover Assembly 7-34
7.13.1 Power Button 7-36
7.13.2 Suspend Button 7-37
7.13.3 Left and Right Touchpad Buttons 7-38
7.14 LED Status Panel 7-40
7.15 Audio Board, Speakers, and Audio Cable 7-41
7.16 DC-DC Converter 7-43
7.17 Fan 7-47
7.18 I/O Fixture Connector 7-49
7.19 System Board 7-51
7.20 AC Power 7-53
7.21 External Computer Components 7-54
7.21.1 Computer Logo 7-54
7.21.2 Computer Feet 7-54
Chapter 8
Upgrade Procedures for the Convenience Base
8.1 Serial Number 8-1
8.2 Preliminary Procedure 8-1
8.2.1 Installing the Optional 100BaseT Ethernet Network Module 8-2
Chapter 9
Specifications
9.1 Computer 9-2
9.2 Displays 9-3
9.3 Hard Drives 9-4
9.4 Diskette Drive 9-5
9.5 CD-ROM Drive 9-6
9.6 Battery Packs 9-7
9.7 Convenience Base 9-8
9.8 External Power Supplies 9-9
9.9 System Interrupts 9-11
9.10 System DMA 9-11
9.11 System I/O Address 9-12
9.12 System Memory Map 9-14
