Display Inverter Board
To remove the display inverter board, follow these steps:
1. Remove the display bezel (Figures 3-5 and 3-6).
2. Remove the display cable and the backlight cable from the display
inverter board in the bottom of the display enclosure by gently pulling
the cables toward you, then unplugging from the inverter board LIF
connector (Figure 3-16).
