Compaq Deskpro EP 6233 - Chapter 3 Processor;Memory Subsystem; Introduction

Technical Reference Guide
Compaq Deskpro EP Series of Personal Computers
First Edition - April 1998
3-1
Chapter 3
PROCESSOR/
MEMORY SUBSYSTEM
3. Chapter 3 PROCESSOR/MEMORY SUBSYSTEM
3.1 INTRODUCTION
This chapter describes the processor/cache memory subsystem of the Compaq Deskpro EP Series
of Personal Computers. Table 3-1 lists the key parameters of the processor/memory subsystem.
Table 3–1.
Processor/Memory Architectural Comparison
Table 3-1.
Processor/Memory
Architectural Comparison
266-MHz
Celeron Processor
266-/300-/333-MHz
Pentium II Processor
350-/400-MHz
Pentium II Processor
North Bridge 82443EX 82443EX 82443BX
Host Bus (Slot 1) Frequency 66 MHz 66 MHz 100 MHz
Cache Memory [1]:
L1
L2
32 KB
none
32 KB
512 KB
32 KB
512 KB
System Memory:
No. of DIMM sockets
Standard installed
Expandable to
2
16/32 MB
256 MB
2
32 MB
256 MB
3
64/128 MB
384 MB
NOTES:
[1] Integrated into the processor cartridge
This description architecturally classifies the processor/memory subsystems as being either a 66-
MHz slot 1 type or a 100-MHz slot 1 type (correlating to the two system board types).
This chapter includes the following topics:
♦
66-MHz slot 1 processor/memory subsystem [3.2] page 3-2
♦
100-MHz slot 1 processor/memory subsystem [3.3] page 3-9
