Product Description
Maintenance and Service Guide 1–7
3 Display release latch Opens the computer.
4 Battery light On: A battery pack is charging.
Blinking: A battery pack that is the only
available power source has reached a
low-battery condition.
5 Battery bay Accepts an 8-cell lithium ion (Li ion)
battery pack.
6 Hard drive bay Supports the removable primary hard drive.
The hard drive is secured to the computer
by one screw.
7 Vent Allows airflow to cool internal components.
Ä
CAUTION: To prevent damage, the computer shuts down if an
overheating condition occurs. Do not block the cooling vent.
Avoid placing the computer on a blanket, rug, or other flexible
surface that may cover the vent area.
8 Security cable slot Attaches an optional security cable to the
computer.
Table 1-6
Front and Right Side Components
(Continued)
Item Component Function
268135-002.book Page 7 Thursday, October 24, 2002 4:10 PM
