C–4 Maintenance and Service Guide
Screw Listing
Figure C-3. Phillips M2.0 × 5.5 Screw Locations
Table C-2
Phillips M2.0 × 5.5 Screw
Color Qty. Length Thread
Head
Width
Silver 2 5.5 mm 2.0 mm 4.0 mm
Where used:
Two screws that secure the connector cover to the computer
(documented in Section 5.7)
268135-002.book Page 4 Thursday, October 24, 2002 4:10 PM
