Screw Listing
Maintenance and Service Guide C–5
Figure C-4. Phillips M2.0 × 5.5 Screw Locations
Table C-2
Phillips M2.0 × 5.5 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 2 5.5 mm 2.0 mm 4.0 mm
Where used:
Two screws that secure the system board to the base enclosure on each side of
the MultiBay connector (documented in Section 5.18)
268135-002.book Page 5 Thursday, October 24, 2002 4:10 PM
