5–20 Maintenance and Service Guide
Removal and Replacement Procedures
6. Remove the two PM2.0 × 4.0 screws 1 that secure the
keyboard shield to the base enclosure (Figure 5-16).
7. Remove the keyboard shield 2.
Figure 5-16. Removing the Keyboard Shield
✎
The keyboard shield is included in the Miscellaneous
Plastics/Hardware Kit, spare part numbers 285261-001 and
286868-001.
