Removal and Replacement Procedures
Maintenance and Service Guide 5–21
8. Release the ZIF connector 1 to which the keyboard cable is
connected and disconnect the keyboard cable 2 from the
system board (Figure 5-17).
9. Remove the keyboard.
Figure 5-17. Removing the Keyboard
Reverse the above procedure to install the keyboard.
268135-002.book Page 21 Thursday, October 24, 2002 4:10 PM
