5.4.3 Connector Cover
The connector cover snaps into place. To remove and replace a connector
cover, complete the following steps:
1. Open the connector cover.
2. Flex the center of the cover away from the computer (Figure 5-17) until
the pivots on each end of the cover disengage the pivot holes in the
computer housing.
