Compaq Presario Internet PC 5000 Series Computers
Jumper and Switch Information
PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG
REMOVAL AND REPLACEMENT
PROCEDURES
JUMPER AND SWITCH
INFORMATION
SPECIFICATIONS
System Board
Hard Drives
CD and DVD Drive/
CD-RW Drive
Internal System Board Connectors
Function Description
DIMM Sockets (3) 168-Pin DIMM
PCI Slots (5) 32 Bit PCI Connector
Clear CMOS 3-Pin Header
USB front I/O connector 10-Pin 0.1 in Connector
Sleep Button & LEDs 2x10 Pin Header
Battery Socket 2-Pin Sacket
CD-ROM Audio (2) 4-Pin Header, Key 2
IDE Drives (2) 40-Pin Headers, Key 20
Disk Drive 34-Pin Header
Internal Fans (2) 3-Pin Intel Standard
Power Supply 20-Pin ATX power supply connector
