Preparation for Disassembly
To prepare the computer for removal and replacement procedures, complete the following
steps:
Remove any disk, compact disc, or tape from the computer.
1.
Turn off the computer and any peripheral devices that are connected to the computer.2.
CAUTION
The computer power switch should be turned off before you disconnect any
cables.
CAUTION
Before doing any work inside your computer, ground yourself by touching a
metal part of the chassis.
Disconnect the power cord from the electrical outlet, and then from the computer.3.
Disconnect all peripheral device cables from the computer.4.
Turn the computer over on its side (open side facing up).5.
IMPORTANT
During disassembly, label each cable as you remove it. Be sure to note its
position and routing.
