Comparc S-512P CV - Section 7 Parts List

PM1395
SECTION 7 PARTS LIST
LIST 7-1 Part List Wire Feeder
IT. No.
QUANTITY
1 PM1017 SUITCASE 1
2 PC2497 CHASSIS 1
3 PM1397 GEARMOTOR 1
4 PS1612 HUB SUPPORT 1
5 MP08414 HUB 1
6 MM04279 GAS HOSE 1
7 PA1056 GEARMOTOR INSULATOR 1
8 MS03964 WIRE TIE 1
9 PT1071 NUT OFF NYLAMID 1
10 MM04282 DYSPLAY FRAME 1
11 PT2566 COVER, COMPONENTS 1
12 PP3907 PLATE, INNER CONTROLS 1
13 PP3905 FRONT 1
14 PA0928 MALE INSULATOR 6
15 PA0929 ISOLATING FEMALE 8
16 PS1634 MOTORGEAR SEPARATOR 1
17 PS1636 MOTORGEAR SEPARATOR 1
18 MS03965 SQUARE BRA 14
19 PC1864 CABLE WELD 1
20 MS04004 STRAIN RELIEF BUSHING 1
21 PT2889 BACK COVER 1
22 MV00768 VALVE SOLENOID 1
23
M F02310
OVERLOAD PROTECTION. CONSISTING OF:
M F00819
FUSE 10A
1
M P00014
FUSE HOLDER
1
24
M T08380
CIRCUIT CARD, CONTROL
1
25
M I01178
SWITCH 1P 1T
1
26
M I00665
SWITCH
2
27
M P02512
POTENTIOMETER
2
28 PC2137
EURO CONNECTOR
1
29 PT2287R
TIMER CARD
1
30 M P03020
POTENTIOMETER 2W
1
31 M P3020
KNOB
3
32 PT2609
DIGITAL VOLTAMMETER CARD
1
33 M I00665
SWITCH
1
34 PS1810
BUS BAR (NOT ILLUSTRATED)
1
PART No. DESCRIPTION
12
