7
Set Button - This button let you do the following:
- Select a port to set/reset an option mode.
- For trunking mode, select/deselect trunk group ports.
- Save and update changes.
After Mode button points to the desired option, press Set button once to
go to port selection mode.
To select a port number, press Set button several times till it jump to
the desired port. To set and save the mode to that port, press the Set
button and hold it down for about 3 seconds until the port LEDs flash
once.
• LEDs
Status LEDs
- Link/Act: Display all active ports link and activity status.
- Speed: Display all active ports speed.
ON for 100Mbps, OFF for 10Mbps.
- FDX/Col: Display all active ports Duplex mode and collision
status.
ON for Full-Duplex mode, OFF for Half-Duplex mode.
Blinks indicate collision active only when port is
operating in Half-Duplex mode.
Option Mode LEDs
- 100M: Set/reset/view pre-set speed for all ports.
- Half: Set/reset/view pre-set duplex mode for all ports.
- Trunking: Set/reset/view pre-set port trunking group(s).
- Priority: Set/reset/view pre-set priority mode for all ports.
- Default: Reset all ports configuration to factory defaults.
