2 Compex 16-Port All 10/100 Switch
DS2216
English
3. Panel Features
(Refer diagrams on inner cover)
Features Status and Indication
1 Power LED Green: Light up when the power supply is ON.
2 Mode Button Button to view port status and select option
mode.
3 Set Button Button to configure port mode.
4 16 RJ-45 Ports
• RJ-45, 100Base-TX/10Base-T ports; Auto-
negotiation.
• Configure as 16 UTP Ports or 15 UTP Ports
plus 1 Uplink Port.
5 Uplink Button
• Uplink mode when button is pushed IN.
• Normal mode when button is released OUT.
6 LINK/ACT LED Select to view active ports link and activity
status.
7 Speed LED Select to view active ports connection speed.
8 FDX/Col LED Select to view active ports duplex mode and
collision status.
9 100M LED Select to configure port speed.
10 Half LED Select to configure port duplex mode.
11 Trunking LED Select to enable/disable and select trunking ports
12 Priority LED Select to set/reset/port priority.
13 Default LED Select to reset switch to factory default setting.
14 Power Socket Flexible power input (range 100-250VAC, 0.5A,
47-63Hz)
