English Compex 16-Port All 10/100 Switch
DS2216
9
8. Advanced Configuration on Compex DS2216
• How to force a certain port to 100Mbps speed and Half or Full-
duplex mode
This is a 2 steps operation.
Note
To configure a port to auto-negotiation mode, turn OFF that port LED
in both 100M and Half mode setup.
1a.
Press the Mode button several times until the 100M LED lights up.
Check the LED for that port number you want to set.
If the port LED lights up it is already forced to 100Mbps mode. Skip
and goto step (2a). Otherwise, proceed to (1b).
1b.
Now press the Set button once will jump to port select. Port #1 LEDs
lights up first. Press the Set button again to jump to next port #2.
Continue to press several times until the desired port LED lights up.
To set this port, press the Set button and hold it down for about 3
seconds until all ports LEDs flash once. When successful, this port
LED will remain lighted up.
2a.
Next press the Mode button until the Half LED lights up. Check the
LED for the port number you want to set.
If it is not lighted up it is in Full-Duplex mode. Do nothing if this is the
mode you want to operate. Setup is completed.
If you want Half-Duplex mode goto to (2b).
If it is lighted up, it is already in Half-Duplex mode. Do nothing if this
is the mode you want to operate. Setup is completed.
If you want Full-Duplex mode goto (2b).
