English Compex 16-Port All 10/100 Switch
DS2216
5
•
Memory Buffer 4M bits
•
Flow Control IEEE 802.3x for full duplex mode.
Back pressure for half duplex mode.
•
Physical Dimension 302mm x 123mm x 53mm (L x D x H)
5. Installation of Compex DS2216
Compex DS2216 can be installed as a desktop unit. Below list the
installation steps.
1. Unpack the unit.
2. Choose a location near the devices to be connected and close to an
electrical outlet. Put the unit at a clean, smooth, level and sturdy place.
Make sure there is enough clearance around the switch to allow
attachment of cables, power cord and adequate air circulation.
3. Plug the power cord into the back of the unit and power on the unit.
Check that the power LED indicator on the unit is lighted up.
4. The unit is now ready to operate.
