10. TECHNICAL SPECIFICATIONS
GENERAL INFORMATION
Remote control battery: Rechargeable 3�7[V] / ≥ 1,500[mAh] lithium polymer (LiPo) battery�
Module battery: Rechargeable 3�7[V] / ≥ 450[mAh] lithium polymer (LiPo) battery�
Compex Wireless USA docking station: Only 5[V] / 3�5 [A] AC power adapters bearing reference number
64902X can be used to recharge your device�
NEUROSTIMULATION
All the electrical specifications are supplied for an impedance from 500 to 1000 ohms per channel�
Outputs: four independent and individually adjustable channels, electrically insulated from one another�
Impulsion form: constant rectangular current with compensated impulses to eliminate any direct element of
continuous current to avoid any residual polarisation from the skin�
Maximum impulse intensity: 120 mA�
Impulse intensity increments: manual adjustment of stimulation intensity from 0 to 999 (energy) by minimum
increments of 0�25 mA�
Duration of impulses: from 300 to 400 μs�
Maximum quantity of electricity per impulse: 96 microcoulombs (2 x 48 μC, compensated)�
Typical impulse rise time: 3 μs (20%-80% of maximum current)�
Frequency of impulses: 1 to 120 Hz�
