CM3000 Wiring Diagram
1 Red 2 Gr/Wht 1: ( + ) 12v Constant 2: ( + ) Parking Light
3 Red/Wht 4 White 3: ( + ) 12v Constant 4: ( + ) Accessory
5 Violet 6 Yellow 5: ( - ) When Armed 6: ( + ) Starter
CN1
7 Gr/Red 8 Black 7: ( + ) Ignition 8: ( - ) Ground
1 Gr/Wht ( - ) Parking Lt. Output 250 mA
2 Black ( - ) Status Out (GWR) 250 mA
3 Green ( - ) Ignition Output 250 mA
Cut = Auto 4 Wht/Blk ( - ) Accessory Output 250 mA
Uncut = Manual
Jumper
CN2
5 Red/Blk ( - ) Starter Output 250 mA
1 Lt. Blue ( - ) E-Brake Input
OFF / ON 2 Gray/Bk ( - ) Hood Input
Altenator / Tach DIP 1 3 Lt. Blue/Wh ( + ) Brake Input
15 (25) / 25 (45) DIP 2
DIP
4 Violet/Blk ( - ) Trunk Input
Gas (Diesel) 5 Red/Wht ( - ) Door Input
6 Red ( + ) Door Input
7 Brown/Blk ( - ) Glow Plug Input
Tach Switch SW
CN12
8 Brown/Wht ( + ) Glow Plug Input
CN3
9 Yellow/Blk Tach / Altenator Input
1 None
4 ( - ) 2 Violet/Wht ( - ) Trunk Release Output 250 mA
3 ( + ) 3 Orange/Blk ( - ) 2nd Unlock Output 250 mA
2 Tx 4 Blue ( - ) Unlock Output 250 mA
Antenna
1 Rx
CN11
5 Blue/Blk ( - ) Lock Output 250 mA
CN4
6 None
1 Orange ( - ) Rearm Output 250 mA
3 ( - ) 2 Orange/Wht ( - ) Disarm Output 250 mA
2 Temp 3 Violet ( - ) Dome Light Supervision 250 mA
Temp Sensor
1 ( + )
CN10
4 Brown ( + ) Siren Output 250 mA
5 White ( - ) Horn Output 250 mA
4 LED 6 Yellow ( - ) Auxiliary 1 Output 250 mA
3 ( + ) 7 Yellow/Wht ( - ) Auxiliary 2 Output 250 mA
2 Knock
CN5
8 None
Remote Paging
System
1 ( - )
CN9
1 Black LED ( - )
2 2nd
CN6
2 Black/Wht LED ( + )
Optional Sensor
Input
1 1st
CN8
1 Black ( - )
2 White 2nd Stage Shock
3 Red ( + )
CN7
4 Yellow 1st Stage Shock
