CM1000A Wiring Diagram
Red 1 ( + ) 12V Constant Input
Violet 2
( + ) Parking Light
Output
Brown 3 ( + ) Siren Output
Gray 4 ( + ) Trunk Output
CN1
Black 5 Ground
Yellow/Blk 1 Normal Closed
Yellow 2
Common - Unlock
Output
Yellow/Wh 3 Normal Open
Green/Blk 4 Normal Closed
Green 5 Common - Lock Output
CN2
Green/Wh 6 Normal Open
Green 1 ( + ) Ignition Input
Blue 2 ( - ) Starter Kill Output 250mA
Red/Blk 3 ( - ) Door Trigger
Red 4 ( + ) Door Trigger
Anrenna Wire Black Violet/Blk 5 ( - ) Trunk Trigger
Lt.Blue/Wh 6 ( + ) Brake Input
CN3
Black/Wh 7
( - ) Optional Sensor
Input
Black 1 ( - ) LED
CN4
Black/Wh 2 ( + ) LED
Black 1 ( - )
White 2
2nd Stage Shock
Sensor
Red 3 ( + )
CN5
Yellow 4 1st Stage Shock Sensor
