CompuSTAR CM1000A - Page 23

- 23 -
Pin 6 Not used.
CONNECTOR 5
Pin 1 Orange- Factory alarm re-arm 250mA (-) negative output. This is an optional
output that will provide a (-) negative pulse output during lock, after crank and after
ignition shut down.
Pin 2 Orange/White- Factory alarm disarm 250mA (-) negative output. This is an
optional output that will provide a (-) negative pulse output during unlock and
before ignition is turned on.
Pin 3 Violet- Dome light 250mA (-) negative output. This is an optional output that will
provide a 30 second (-) negative output after system is unlocked for dome-light
supervision.
Pin 4 Brown- Siren 12-volt (+) positive output. This wire will provide a 30 or 60 second
(+) positive output for the external siren. (Note: Factory default is 30 seconds.)
Pin 5 White- Horn honk 250mA (-) negative output. This is an optional output that will
provide a 30 or 60 second (-) negative pulse when the alarm is triggered or during
panic.
Pin 6 Yellow- Aux 1- 250mA (-) negative output. This is an optional output that will
provide a pulse, latch or a timed pulse output. (Note: Options programmer is
required to program a timed pulse output.)
Pin 7 Yellow/White- Aux 2- 250mA (-) negative output. This is an optional output that
will provide a pulse, latch or a timed pulse output. (Note: Options programmer is
required to program a timed pulse output.)
Pin 8 Not used.
CONNECTOR 6
(Pre-wired L.E.D.)
Pin 1 Black-L.E.D. - (-) negative output.
Pin 2 Black/White - 3-volt L.E.D. (+) positive output.
