CompuSTAR CM1000A - Page 25

- 25 -
CONNECTOR 11
(Pre-wired Antenna Cable)
Pin 1 Yellow
-RX input. This wire receives signal from remote.
Pin 2 White-TX output. This wire transmits signal to remote.
Pin 3 Red
-12-volt constant (+) positive input.
Pin 4 Black
- (-) negative ground input.
