CompuSTAR CM1000A - Page 28

- 28 -
CM-3300 WIRING DETAIL
CONNECTOR 1
Pin 1 Brown- Siren 12-volt (+) positive output. This wire will provide a 30 or 60 second
(+) positive output for the external siren. (Note: Factory default is 30 seconds.)
Pin 2 Green/White- Parking light (+) positive output. Connect this wire to the (+)
positive parking light wire generally at the parking light switch or behind the fuse
box. The proper wire will test 12-volts (+) positive when the parking light switch is
in the on position.
Pin 1 Red- Constant 12-volt (+) positive power input for the control module. This wire
must be connected to a constant 12-volt (+) positive source. The proper wire will
test 12-volt (+) positive with the key in the off position, while key is in the on
position and during crank.
Pin 4 Black- Ground (-) negative input. This wire will connect to chassis ground.
CONNECTOR 2
Pin 1 Green/White- Parking light 250mA (-) negative output. This is an optional output
that will provide a (-) negative output with parking light flash.
Pin 2 White- Horn honk 250mA (-) negative output. This is an optional output that will
provide a 30 or 60 second (-) negative pulse when the alarm is triggered or during
panic.
Pin 3 Yellow- Aux 1- 250mA (-) negative output. This is an optional output that will
provide a pulse, latch or a timed pulse output. (Note: Options programmer is
required to program a timed pulse output.)
Pin 4 Yellow/White
- Aux 2- 250mA (-) negative output. This is an optional output that
will provide a pulse, latch or a timed pulse output. (Note: Options programmer is
required to program a timed pulse output.)
Pin 5 Violet-
250mA (-) negative output when armed. This wire will provide a (-)
negative output when system is locked and armed. (Note: This wire can also be
used to trigger after-market L.E.D. kits and other after-market accessories. Output
must be diode isolated when used to trigger after-market accessories.)
