CONNECTOR 4
Pin 1 Not used
Pin 2 Violet/White
- Trunk release 250mA (-) negative output. This wire will provide a (-
) negative trigger pulse. (Note: Positive trigger trunk release will require a relay.
System will unlock doors and disarm alarm prior to trunk release.)
Pin 3 Orange/Black- 2
nd
Unlock 250mA (-) negative output. This wire is an optional
output that will provide a (-) negative pulse output for driver’s priority door lock.
(Note: This feature will require additional relays and programming.)
Pin 4 Blue- Unlock 250mA (-) negative output. This wire will provide a (-) negative
pulse output during unlock and disarm. (Note: Positive and reverse polarity will
require additional relays.)
Pin 5 Blue/Black- Lock 250mA (-) negative output. This wire will provide a (-) negative
pulse output during lock and arm. (Note: Positive and reverse polarity will require
additional relays.
Pin 6 Not used.
CONNECTOR 5
(Pre-wired L.E.D.)
Pin 1 Black-L.E.D. - (-) negative output.
Pin 2 Black/White
- 3-volt L.E.D. (+) positive output.
CONNECTOR 6
(Pre-wired Shock Sensor)
Pin 1 Black-Shock sensor (-) negative ground input.
Pin 2 White
-Shock sensor 2
nd
stage (-) negative input. (Instant trigger)
Pin 3 Red
-Shock sensor 12-volt (+) positive input.
Pin 4 Yellow-Shock sensor 1
st
stage (-) negative input. (Warn away)
