- 36 -
Pin 3 Light Blue/White- Brake 12-volts (+) positive input. This input is required to shut
down vehicle when remote started. The proper wire will test 12-volts (+) positive
only when the foot brake is pressed.
Pin 4 Violet/Black- Trunk-pin (-) negative input. This is an optional input that will
monitor when the vehicles trunk is opened. (Note: This wire will also trigger the
alarm when the system is armed.)
Pin 5 Red/White
- Door trigger (-) negative input. This wire monitors (-) negative trigger
door-pins. The proper wire will provide a (-) negative trigger only when the doors
are opened. (Note: This wire is required for manual transmission remote starts.)
Pin 6 Red
- Door trigger (+) positive input. This wire monitors (+) positive trigger door-
pins. The proper wire will provide a (+) positive trigger only when the doors are
opened. (Note: This wire is required for manual transmission remote starts.)
Pin 7 Brown/Black- Glow plug (-) negative input. This wire will delay the starter output
to allow the glow plugs to warm up on diesel engine vehicles. The proper wire will
only provide a (-) negative trigger while the “Wait to Start” light is on.
Pin 8 Brown/White- Glow plug (+) positive input. This wire will delay the starter output
to allow the glow plugs to warm up on diesel engine vehicles. The proper wire will
only provide a (+) positive trigger while the “Wait to Start” light is on.
Pin 9 Yellow/Black- Engine sensing input. A tach input or alternator input is required for
the system to sense when the vehicle is running. (Note: Option selected by
dipswitch #1. On=Tach sensing. Off=Alternator sensing.)
CONNECTOR 4
Pin 1 Not used
Pin 2 Violet/White- Trunk release 250mA (-) negative output. This wire will provide a (-
) negative trigger pulse. (Note: Positive trigger trunk release will require a relay.
System will unlock doors prior to trunk release.)
Pin 3 Orange/Black- 2
nd
Unlock 250mA (-) negative output. This is an optional output
that will provide a (-) negative pulse output for driver’s priority door lock. (Note:
This feature will require additional relays and programming.)
Pin 4 Blue- Unlock 250mA (-) negative output. This wire will provide a (-) negative
pulse output during unlock. (Note: Positive and reverse polarity will require
additional relays.)
