- 42 -
Pin 6 Light Blue/White- Brake 12-volts (+) positive input. This input is used for ignition
controlled door locks. The proper wire will test 12-volts (+) positive only when the
foot brake is pressed.
Pin 7 Black /White- Optional sensor (-) negative input. (Instant trigger)
CONNECTOR 4
(Pre-wired L.E.D.)
Pin 1 Black-L.E.D.- (-) negative output.
Pin 2 Black/White
-3-volt L.E.D. (+) positive output.
CONNECTOR 5
(Pre-wired Shock Sensor)
Pin 1 Black-Shock sensor (-) negative ground input.
Pin 2 White-Shock sensor 2
nd
stage (-) negative input. (Instant trigger)
Pin 3 Red-Shock sensor 12-volt (+) positive input.
Pin 4 Yellow-Shock sensor 1
st
stage (-) negative input. (Warn away)
