12-3
Changing Transceiver Control Status by Radio
To change the status of a channel, key-up and send the control operator code [100] followed by the zone
number, channel number and a [1] to turn the channel ON or a [0] to turn the channel OFF. Un-key and
the voice will read back the zone, channel number and control activity. The voice will say: "ONE ONE
ON." or "THREE FIVE OFF." Example: With a control operator prefix of 100, turn Zone 3 Channel 6 ON.
Un-key and the voice will say: "THREE SIX ON."
Zone 1
1 Transceiver Transmit Enable*
2 Transceiver Identification Enable*
3 DTMF Pad Test Enable*
4 Weather Report Enable*
5 CTCSS Encoder Switch Enable
6 Reserved Enable
7 Reserved Enable
8 Reserved Enable
Zone 3
* During initialization these control channels are set to the enable position.
1 Logic Input #1 Enable*
2 Logic Input #1 Enable*
3 Logic Input #1 Enable*
4 Logic Input #1 Enable*
5 Output Switch #1 Enable
6 Output Switch #2 Enable
7 Output Switch #3 Enable
8 Output Switch #4 Enable
Zone (1 – 3) Channel (1 through 8)
Control Operator Code Activity (0=OFF 1=ON)
Key-up and send: 100 3 6 1
