CONCEPT2.COM
Page 2
012611
CONCEPT2 DYNAMIC INDOOR ROWER
Assembly Instructions
Step 1. Open the two boxes and remove all the parts. Lay out the parts as shown below and read
through the assembly instructions before beginning assembly.
Foot Carriage
Flywheel Return Assembly
Shuttle
Channel
Rail Assembly
Front Leg/Monitor Arm Assembly
Rear Foot
Handle
Installation
leader tape
Parts for Assembly
2 PN 2227 T27 6 lobe drive x
1/2” patched rev. ss
11 PN 2228 T27 6 lobe drive
x 1 3/8” patched rev. ss
1 Rail Assembly
End Stop w/2 nuts
1 Front Leg End Cap
1 6 lobe Driver
2 20-penny nails
9 PN 2239 T27 6 lobe drive x
3/8” patched rev. ss
(Located in plastic
bag with manuals)
