34
Icon instruction：
Icon
Function instruction
return to the main menu
click on the pop-up menu, such as modifying parameters, name options
shot
catalogue
device
after pop-up, add the catalogue,, device and shot menu
search the local shot
6.1.5.1 Modify the connection parameter
Click on the icon , select “modify connect parameter”, then into “modify device” dialog box：
A）Click on the icon , return to the device management lists.
B）Click on the icon , save the current configuration.
6.1.5.2 Modify the name
Click on the icon , select the option “modify the name”, then pops up “modify name” or “modify the catalogue” dialog box.
