ROUTER DESCRIPTION
5.3. Ordering code
5.3.1. Basic version
Expansion port Ordering code
Version without expansion port LR77 v2B set
Version with expansion Ethernet port LR77 v2B set ETH
Version with expansion RS232 port LR77 v2B set RS232
Version with expansion RS485 port LR77 v2B set RS458
Version with expansion MBUS port LR77 v2B set MBUS
Version with expansion CNT port LR77 v2B set CNT
Table 4: Ordering code of basic version
5.3.2. Full version
Expansion port Possible participation Ordering code
Version without expansion port LR77 v2F set
Version with expansion Ethernet port PORT1 LR77 v2F ETH set
Version with expansion RS232 port PORT1 a PORT2 LR77 v2F RS232 set
Version with expansion RS485 port PORT1 a PORT2 LR77 v2F RS458 set
Version with expansion MBUS port PORT1 a PORT2 LR77 v2F MBUS set
Version with expansion CNT port PORT1 LR77 v2F CNT set
Version with expansion XC-SW port PORT1 + PORT2 LR77 v2F SWITCH set
Table 5: Ordering code of full version
Second expansion port is written after first expansion port in the ordering code.
Example:
• Full version with Ethernet and RS232 port: LR77 v2F ETH RS232 set.
• Full version with Ethernet and RS232 port in metal cover:
LR77 v2F SL ETH RS232 set.
6
