ROUTER DESCRIPTION
5.7.3. Antenna connector ANT and AUX
The antenna is connected to the router using the SMA connector on the front panel.
The router can not operate without the main antenna connected labeled as ANT.
ANT connector used to connect the main antenna router. To connect the second
antenna for diversity income is used second connector AUX.
Example of antenna:
Fig. 21: External antenna
The antenna with the SMA connector. The antenna is connected to screw the antenna
connector SMA to SMA connector on the router head (see figure below).
Fig. 22: Connecting the antenna
Diversity antenna improves wireless features of router in weak signal strength.
13
