TECHNICAL PARAMETERS

7.3. Technical parameters of processor

32b ARM microprocessor

Memory 512Mb DDR SDRAM

128Mb FLASH

1Mb MRAM

Interface Serial interface RS232

Ethernet interface 10/100Mbit/s

USB 2.0 interface

Table 15: Technical parameters of processor

7.4. Technical parameters I/O port

Port IO

Input/Output Binary input reed contact

with trigger level

1,3 up to 1,4 V

Binary output 120 mA/max. 30 V

Table 16: Technical parameters of I/O port

7.5. Technical parameters of expansion port

Technical parameters of the expansion ports are to be found in separate manuals

for expansion ports.
