TECHNICAL PARAMETRES
7. Technical parameters
7.1. Technical parameters of router
LR77 v2
Complies with standards EN 301 511, v9.0.2,
EN 301 908-1&2, v3.2.1,
ETSI EN 301 489-1 V1.8.1,
EN 60950-1:06 ed.2 + A11:09 + A1:10
Temperature range Function
Storage
-30
o
C to +60
o
C
-40
o
C to +85
o
C
Protection Freely
In switch board
IP20
IP56
Supply voltage 10 to 30 V DC
Consumption Reception
GPRS
LTE
300 mW
to 3,5 W (GPRS transmission)
to 5,5 W (LTE transmission)
Dimensions 42 x 76 x 113 mm (DIN 35 mm)
Weight LR77 v2 – 150 g
LR77 v2 SL – 280 g
Antenna connector SMA – 50 Ohm
User interface ETH
USB
PORT1
PORT2
Ethernet (10/100 Mbit/s)
USB 2.0 type A host
At customer's request
At customer's request
Table 13: Technical parameters of router
7.2. Technical parameters of module
LTE module
LTE parametry bit rate 100 Mbps / 50 Mbps
3GPP rel. 8 standard
supported bandwidth – 5Mhz, 10Mhz, 20Mhz
HSPA+ parameters bit rate 21.1 Mbps/5,76 Mbps
3GPP rel. 7 standard
UE CAT. 1 to 6, 8, 10, 12, 14
Data compress 3GPP
UMTS parameters PS bitrate – 384/384 kbps
CS bitrate – 64/64 kbps
W-CDMA FDD standard
GPRS parameters bit rate 236 kbps/236kbps
GPRS multislot class 10, CS 1 to 4
EDGE multislot class 12, CS 1 to 4,
MCS 1 to 9
Transmit power UMTS/HSUPA/HSDPA/HSPA+ – (20dBm)
EGSM 900 – Class 4 (33dBm)
GSM 1800/1900 – Class 1 (30dBm)
Support channel GSM/GPRS/EDGE – 900Mhz, 1800Mhz, 1900Mhz
UMTS/HSDPA/HSUPA/HSPA+ – 900Mhz, 2100Mhz
LTE – 800Mhz, 900Mhz, 1800Mhz, 2100Mhz, 2600Mhz
Table 14: Technical parameters of module
