Conlan C1000LP - Output Settings Configuration

5.6 Outputs
The C1000LP has 2 outputs that can be set to H-Bridge output or open collector out-
put.BydefaultistheC1000LPsettoH-BridgeoutputwithLockdelayin5seconds.
Toconguretheoutputsettingsusethefollowingsteps:
○ ● ○ ○ ● ●
sets the output 1 time in Pulse mode or Lock delay
sets the output 2 time in Pulse mode or H-Bridge time
sets the output 1 active position
sets the output 2 active position
sets the outputs functions
select the outputs for Daycode/onetime code
Pleaseusethecongurationschemeunder“03”sectionforcorrectnavigationforOC
setup
Note: In time setting for Pulse mode it is in Milisec x 10 instead of hours.
10
#
Key in the
Service code
#
Key in
03
1
2
3
4
5
6
